Catalog number: TCD
Copper cable lug manufactured from electrolytic copper with a tinplated finish to improve electrical contact. According to DIN 46235.
Cross section: 120 mm²
Copper type: 99,9% electrolytic copper
Specific gravity: 8,95 g/cm³
Conductivity at 20 °C: 58,14 S x m/mm²
Resistivity at 20 °C: 0,0192 Ω x mm²/m
Surface treatment: tin bath 5μ thick
